MAGNEHELIC ® DIFFERENTIAL PRESSURE GAGES

Indicate Positive, Negative or Differential, Accurate within 1%

Select the Series 2000 Magnehelic ® Differential Pressure Gages for a versatile low differential pressure gage with a wide choice of 81 models and 27 options to choose from.

Using Dwyer’s simple, frictionless Magnehelic ® gage movement, it quickly indicates air or non-corrosive gas pressures--either positive, negative (vacuum) or differential. The design resists shock, vibration, over-pressures and is weatherproof to IP67.

Select the –HA High Accuracy Magnehelic ® gage option for an accuracy within 1% of full-scale. Also included with the –HA option at no extra cost are a mirrored scale overlay and a 6 point calibration certificate.

BENEFITS/FEATURES

• Easy to read gage through undistorted plastic face permits viewing from far away

• Patented design provides quick response to pressure changes means no delay in

 assessing critical situations

• Durable and rugged housing and high-quality components combine to provide long-

 service life and minimized down-time

• High accuracy option is twice as accurate as the standard Magnehelic ® gage

APPLICATIONS

• Filter monitoring

• Air velocity with Dwyer pitot tube

• Blower vacuum monitoring

• Fan pressure indication

• Duct, room or building pressures

• Clean room positive pressure indication

검교정 대행

검교정 대행이 가능하여 검교정이 완료된 제품을 바로 받아보실 수 있습니다.
